Modular Desiccant Dryers
Modular AXM
High-performance desiccant air treatment
By combining the proven benefits of desiccant drying with modern design, CompAir provides an extremely compact and reliable system to dry and clean compressed air efficiently.
The CompAir A-Series of heatless regenerative desiccant dryers have proven to be the ideal solution for many thousands of compressed air users worldwide in a wide variety of industries.
High Air Quality:
Delivers ISO Class 2 or Class 1 pressure dew point air for critical applications; high efficiency pre and post-filters provide constant high air quality, protecting downstream air from contamination.
Superior Reliability:
Proven electronic control performance indicators, extruded aluminium with anodisation and epoxy painting, and NEMA 3/IP54 Protection (also suitable for outdoor installation) make desiccant dryers durable and high-strength.
Total Cost of Investment:
Reduced cost of ownership with point of use design to treat only the required air, conservative pressure drop 0.2 Barg, and purge reduction on compressed air demand (on/off-load).
Ease of Use:
User-friendly electronic interface with alarm indicators available for models 40 and above.
Serviceability:
Modular dryers feature an optimised design for simplified maintenance and preventative maintenance alerts (models 40 and above).
Compact & Flexible Solution:
Space-saving design for optimised installation with air inlet and outlet in the back of unit and connection piping can come from right or left. Model up to 0.42 m3/min can be wall-mounted or installed horizontally
Performance Improvement:
Extended rated pressure range from 4 to 14 Barg and increased airflow range coverage up to 300 m³/h. Guaranteed class 2 (-40°C) and optionally class 1 (-70°C) pressure dew point.
Longer Cycle Life:
Modular dryers have a longer cycle time, 10 minutes, than most competitors (4 to 8 minutes maximum).
